The SCOTT Roxter 16 is our truly functional bike for smaller riders who like a race-inspired style.

A Head Tube Angle 70°
B Head Tube Length 90mm
C Top Tube Horizontal 395mm
D Standover Height 452mm
F BB Height 105mm
G Wheel Base 718mm
H BB Center To Toptube Center 155mm
I BB Center To Top Of Seattube 210mm
J Seat Angle 70°
K Chainstay 290mm
L Reach 276.4mm
M Stack 325.8mm


Frame JR16 Coaster Alloy 6061, Bent TT Semi int. HT, Rigid Fork
Fork BMX Type, rigid HiTen, 16", V-Brake Pivot
Rims Alloy, black, 20H/28H, A/V
Hubs Front: KT-183F, 20H, Nutted
Rear: KT-305RB, 28H, Nutted Coaster brake
Spokes 15g UCP, black
Tires Front: Kenda K841 Contact, 16x2.25"
Rear: Kenda K841 Contact, 16x2.25"
Bottom Bracket Steel, loose ball bearings
Crankset One Piece Crank, 28T
Cassette/Freewheel 18T
Chain KMC S1
Brakes F: V-Brake R: Coaster
Brake Levers Kids Lever Alloy
Handlebars Junior mini riser bar 500mm
Stem Ahead, Alloy, 30mm, 25.4mm clamp
Headset Semi integrated 1 1/8"
Seatpost Alloy 26.8x200mm
Saddle Syncros Roxter JR16
Pedals MARWI SP-201, 1/2", w/Reflector
Accessories & Extras Kickstand, Full-chainguard, Syncros Stem Protector

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Green / 16-inch 192820614472 286633222 210000001732
